BOJACK 60/15 uF 60+15 MFD 370/440 VAC CBB65B Dual Run Start Round Capacitor for Condenser Straight Cool or Heat Pump Air Conditioner or AC Motor and Fan Starting
Product details
| Management number | 218167687 | Release Date | 2026/05/03 | List Price | $9.04 | Model Number | 218167687 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
BOJACK Dual run circular start capacitor ombines two capacitors into one unit. Three terminals on the top are labeled "Herm"/"H" for the compressor motor, "Fan"/"F" for the fan, and "C" for the common line.It will power a compressor motor and a fan motor Model: CBB65B（Universal model） Shell material: metal Dielectric Material: metallized polypropylene film Capacity: 60+15uf Tolerance: ±6% Rated voltage: 440V AC Frequency: 50 / 60Hz Safety rated: 10,000 AFC Operating temperature:-40℃ to +70℃/-104℉ to +158℉ This capacitor is used for start-up and operation of AC motors with frequency of 50Hz/60Hz such as Industrial Grade Replacement for Central Air-Conditioners, Heat Pumps, Condenser Fan Motors, and Compressors. It is small in size, lightweight, heat resisting and anti-explosion. Round capacitor can be used to substitute oval shape one with the same MFD AND Volt specs.A 440 volt capacitor can be used in place of a 370 volt, as it is build better, but the 370 can’t be used in place of a 440 volt.
- BOJACK 60+15 uF ±6% 370/440 VAC CBB65B dual run start capacitor replacement for BOTH 370 & 440 Volt capacitors.
- Capacitance tolerance: ± 6%
- Rated voltage: 370V / 440VAC
- Allowable working temperature: -40 ℃ to 70 ℃
- Safety protection level: S1
| Model | BJ-CPA-6015 |
|---|---|
| Brand Name | BOJACK |
| Item Shape | Round |
| Capacitance | 75 Microfarad |
| Part Number | BJ-CPA-6015 |
| Manufacturer | BOJACK |
| Material Type | Aluminum, Polypropylene |
| Mounting Type | Through-Hole Mount |
| Operating Voltage | 440 Volts (AC) |
| Included Components | Capacitor |
| Upper Temperature Rating | 70 Degrees Celsius |
| Maximum Storage Temperature | 70 Degrees Celsius |
